Rawson Accu-Rate/Accu-Plant PFadvantage
Application Rate Mode Ag Leader Technology
September 2003 2-68
Setup for
Rawson Accu-
Rate or Accu-
Plant Controller
Complete the following steps to setup for Rawson Accu-Rate or
Accu-Plant.
A separate configuration of settings should be created for every
product applied. A maximum of 16 different configurations can be
created. The screen below illustrates two configurations for a
Accu-Rate controller.
1. Press SETUP key. Press APP RATE CONFIG key. A screen
similar to the one below should appear:
APP RATE CONFIG
PRODUCT CONTROLLER CHANNEL
Corn ACCU-RATE N/A
Hybrid B ACCU-RATE N/A
EDIT
SETTINGS
CREATE
NEW
DELETE EXIT
Press CREATE NEW key to set up a new configuration or select an
existing configuration and press the EDIT SETTINGS key. A new
screen appears with the following settings. Select each setting and
press EDIT key to change the settings.
Controller Make: Set to RAWSON.
Controller Model: Set to ACCU-RATE or ACCU-PLANT.
Product: Press EDIT key. You can select an existing product and
press ACCEPT key or create a new product by pressing CREATE
NEW key. Press EDIT NAME key and enter name of product. Use
Left or Right Arrow keys to select a character. Use Up or Down
Arrow key to change the character. To erase a character in the name,
highlight that character and use UP or DOWN ARROW key to scroll
to the blank space between "9" and "A". Set every character and
press ACCEPT key twice.
