Marking PFadvantage
All Modes Ag Leader Technology
September 2003 4-14
Introduction You must have a memory card to do field marking. To perform field
marking you can use the internal marker selection keys built into the
PFadvantage or connect the external field marker device. You can not use
both at the same time. You can make marks in all operating modes of the
PFadvantage.
IMPORTANT: Make sure that under the CONSOLE setup key, you
have the Field Marker set correctly to either INTERNAL or
EXTERNAL.
If you are using the internal marks, you can rename the marks and also set
them up as a continuous or spot mark. If you are using the external Field
Marker, you can not rename the marks but can do continuous or spot
marking.
Continuous marking
Making several marks in a row (for example: marking large weed
patches or tile lines).
Spot marking
Marking just one mark (for example: marking a rock or tile hole).
Setting Up Marks Press the SETUP key and MARKS key to display the marker setup screen
and name and set the internal marks. If you are using the external Field
Marker, you do not need to make any settings on the Marker Setup screen.
Making Marks You can mark more than one item at a time. When a mark is turned on the
monitor will beep and the mark will flash.
Follow the steps below to make marks when using the internal marks.
Step Action
1 Display FIELD, LOAD, SHOW MAP, OPTIONS on the bottom
by pressing the MENU key .
2 Press the OPTIONS key to display the marker keys on the bottom.
