PFadvantage Area Counting
Ag Leader Technology All Modes
September 2003 4-11
Calibration Step Action
Procedure 1 Change the field to a field for which you know the exact area.
Select (rectangular box surrounds line) the field by pressing the key
to the right of the line displaying field. Use the UP or DOWN
ARROW keys to change the field.
2 Select the “Actual Area” line by pressing the key to the right of the
line displaying actual area. Use the UP or DOWN ARROW keys to
set the actual area.
3 Press the PERFORM CAL key. Press the ACCEPT key.
4 Repeat steps 1-4 for all the fields for which you know the actual
area.
5 Press the EXIT key once you have finished.
Note:
• The monitor proportionally adjusts all the load areas so that the areas
from all the loads equal the total field area.
• The “Area Cal” number is the actual area divided by the area the
monitor originally counted. When you press the PERFORM CAL key,
the monitor determines the area calibration number and adjusts the
measured area accordingly.
• Usually the monitor will have slight errors when turning on the ends
due to mechanical limitation of not turning area on and off exactly at
the start and end of a pass. Typical area calibration numbers for
harvesting row crops are 97-99% and for non rowed crops, 96-98%.
* * *
