Area Counting PFadvantage
All Modes Ag Leader Technology
September 2003 4-8
Introduction In the bottom right corner of the display, the monitor always displays either:
• AREA ON
or
• AREA OFF
The area count switch is located on the bottom right corner of the front
panel. The switch manually controls area counting. The header sensor or
implement switch or spray booms automatically turns area counting on and
off if the area count switch is in the up position.
When the switch is in the down position, the monitor displays and flashes
“Area Off” and stops counting area.
When the switch is in the up position, the monitor will display “Area On”
and count area unless the header sensor or implement switch or spray
booms are connected and are automatically shutting off area counting.
Stop Height The stop height number in the monitor determines at what head position the
monitor will turn on and off area counting. Refer to the calibrating stop
height instructions in the calibration section.
If your monitor is set on the site verification mode and you have an
implement switch set the stop height to 50.
The stop height number can be set differently for each grain type. The stop
height setting normally will be between 55 and 80 for header sensors on
most combines.
