PFadvantage Raven Controller (with Serial Port)
Ag Leader Technology Application Rate Mode
September 2003 2-45
APP RATE CONFIG
PRODUCT CONTROLLER CHANNEL
Treflan 440 Rate 1
Roundup 440 Rate 1
EDIT
SETTINGS
CREATE
NEW
DELETE EXIT
Press CREATE NEW key to set up a new configuration or
select an existing configuration and press the EDIT
SETTINGS key. A new screen appears with the following
settings. Select each setting and press EDIT key to change the
settings.
Controller Make: Set to RAVEN. This setting can not be
changed once the configuration is used by one or more fields.
Controller Model: Set to the Raven model you have. For
example: 440 or 460 etc. This setting can not be changed once
the configuration is used by one or more fields.
Product: Press EDIT key. You can select an existing product
and press ACCEPT key or create a new product by pressing
CREATE NEW key. Press EDIT NAME key and enter name
of product. Use Left or Right Arrow keys to select a character.
Use Up or Down Arrow key to change the character. To erase
a character in the name, highlight that character and use UP or
DOWN ARROW key to scroll to the blank space between "9"
and "A". Set every character and press ACCEPT key twice.
Units: Usually set to GALLONS. Set to Units/Acre of
application.
Ground Speed Sensor: Set primary speed sensor to GPS.
SERIAL is not recommended. RADAR is an option but you
will need additional cabling to connect the radar to your
monitor. All Ag Leader GPS except GPS 1000 will work for
ground speed.
Note: This setting affects all configurations.
