PFadvantage Console Setup
Ag Leader Technology All Modes
September 2003 2-7
Operating mode The PFadvantage has the following operating modes: Grain Harvest, Grass
Seed Harvest, Cotton Harvest, HarvestMaster™, Application Rate and Site
Verification. Upon changing the operating mode you should make sure all
setup items for that operating mode are correct.
To switch modes, you must install that modes operating firmware. The
exception is Site Verification Mode. Site Verification is available with all
other modes. See "Updating Operating Program" instructions in the
Operation Section of this manual to load different firmware. All firmware
versions are on the CD that that came with the monitor or on the web at
www.agleader.com.
Units of Measure The PFadvantage can display information in either Imperial or Metric units
of measure.
Month/Day/Year
Time Set to the current date and time. These numbers should be set correctly
from the factory.
Serial number,
Box calibration,
Voltage calibration The serial number, box calibration number and voltage calibration number
can be found on the bottom side of the monitor. These numbers should be
set correctly from the factory.
GPS Check Sum GPS Check Sum setting is used to enable or disable data string error
checking. Normally set to ON.
Field Marker If you are... Select
Marking field points with the PFadvantage’s
internal marker selection keys. INTERNAL
Marking field points with an external Ag Leader
Field Marker. EXTERNAL
Adjust Display
Brightness To adjust the display back lighting, scroll down to "Display brightness" and
press EDIT key. Use the UP or DOWN ARROW keys to adjust the screen
brightness and press the ACCEPT key.
* * *
