Raven Controller (with Serial Port) PFadvantage
Application Rate Mode Ag Leader Technology
September 2003 2-48
Actual Rate Units: Ignore this setting.
Log Actual Rate: Set to YES to log actual rate to card.
Set to No, otherwise.
4. This completes all the settings for one configuration. Press
EXIT key twice to return to screen showing all configurations
or press EXIT key 3 times and menu key to return to main
operating system.
Activating
Configuration and
Setting .tgt
Prescription File
5. Exit back to main screen.
a) Press FIELD key twice.
b) Select appropriate field and press VIEW CONFIG key.
c) Select appropriate product/controller configuration and
press ACTIVE ON/OFF key to check it as active. (All
other configurations must be unchecked first).
d) If you will be using a .tgt prescription file. Press EDIT
TGT FILE key, otherwise press EXIT key and skip to
step f.
e) Select .tgt file. Press VIEW INFO key to ensure it is
the correct one. After exiting view info screen, press
ACCEPT key. Press EXIT key.
f) Press ACCEPT key to accept field.
Settings for Raven.
Under Data Menu key, set Baud = 9600, Trig = 1, Unit = sec,
Dlog = ON. To turn the rate change alarm OFF set Rate = OFF.
On some Ravens the Dlog setting has to be reset when the
console is turned ON.
Additional
Instructions
For more information on setting Target Rate, display items,
creating and using .tgt prescription files and logging actual rate see
the Operation Section in this manual.
