Description Item
LDEV attribute
Displays the attribute of the LDEV. Attribute
• Command Device: Command device.
•
Remote Command Device: Remote command device.
• Reserved VOL: Reserved volume.
•
TSE: TSE-VOL.
•
Nondisruptive Migration: Volume for the nondisruptive migration.
• -: Volume in which the attribute is not defined.
Removes LUN paths from the Selected LUN Paths table. Remove from Delete process
Removes LUN paths from the Selected LUN Paths table. Delete all defined LUN paths to above
LDEVs
When this check box is selected, the host groups of all the alternate paths
in the LDEV displayed in the Selected LUNs table must be assigned to the
Storage Administrator group permitted to manage them.
Click Next to go to the task setting window, which is indicated in Task Next
Option. Next Task Option
Confirm window
Confirm proposed settings, name the task, and then click Apply. The task will be added to the
execution queue.
Selected LUN Paths table
Description Item
Identifier of the port. Port ID
Identifier of the selected LUN path. LUN ID
LDEV identifier, which is the combination of LDKC, CU, and LDEV. LDEV ID
Name of the LDEV. LDEV Name
Name of the host group. Host Group Name
366 LUN Manager GUI reference
