Concatenated LDEVs(LUSE) table
If the is the top LDEV the component in the LUSE volume, the information about the LDEV is not
displayed.
Description Item
Displays the LDEV ID. LDEV ID
Displays the LDEV name. LDEV Name
Displays the parity group ID. Parity Group ID
Displays the emulation type. Emulation Type
Displays the capacity of the LDEV. Individual Capacity
Displays the attribute of the LDEV in the LUSE volume. The Top is displayed
if the LDEV locates in the top of the LUSE volume. The Member is displayed
if the LDEV locates in the LUSE volume other than the top. LUSE Attribute
Local Replication Tab
Information about the volume of the local replication pair is displayed in the Replication Properties,
and Pairs tables.
For details about each item, see HP P9000 Business Copy User Guide or HP P9000 Snapshot
User Guide.
Replication Properties table
Description Item
Displays the status of the Business Copy L1 pair. Business Copy L1
Displays the status of the Business Copy L2 pair. Business Copy L2
Displays the status of the Snapshot pair. Snapshot
Displays the status of the Business Copy Z pair. Business Copy for Mainframe
Displays the status of the Compatible FlashCopy relationship. Compatible FlashCopy
Displays the status of the Compatible FlashCopy SE relationship. Compatible FlashCopy SE
If the volume is the reserved volume for the pair, Yes is displayed. If the
volume other than the reserved volume is specified, No is displayed. Reserve Volume
Pairs table
Description Item
Displays LDEV ID, LDEV Name, Emulation type, Capacity, CLPR ID, and
CLPR name of the primary volume. Primary Volume
Displays the copy type of the pair. Copy Type
Displays the pair status. Status
Displays LDEV ID, LDEV Name, Emulation type, Capacity, CLPR ID, and
CLPR name of the secondary volume. Secondary Volume
Displays the date when the Snapshot data of the pair was stored. Snapshot Date
Displays the pool name(ID) of the pair. Pool Name(ID)
Displays the pace of copying of the pair. Copy Pace
262 LDEV GUI reference
