Physical Location table
Description Item
Location where the free spaces and LDEVs are assigned. Physical Location No.
Free space number. The hyphenation appears for volumes other than free spaces. Free Space No.
LDEV identifier. A hyphen (-) appears for other than LDEV IDs. LDEV ID
LDEV name. A hyphen (-) appears for volumes other than LDEVs. LDEV Name
Emulation type. A hyphen (-) appears for volumes other than LDEVs. Emulation Type
Capacity of the LDEV. Capacity
Number of paths set for the LDEV. A hyphen (-) appears for volumes other than
LDEVs. Number of Paths
Edit SSIDs window
Use this window to select a storage system identifier whose properties can be changed.
Description Item
LDKC number. LDKC
Control unit number. CU
The range of LDEVs that can be allocated to the SSID. Each LDEV group (divided
by LDEV boundary) has a unique SSID. LDEV Boundary
Storage system identifier in hexadecimal format. SSID
Indicates whether the storage system identifier is can be changed. SSID Changeable
• Yes: The SSID can be changed. The SSID was assigned when creating LDEVs
but has not yet been registered (unused).
•
No: The SSID can not be changed. The SSID has been registered (used) and
cannot be changed.
• Hyphen (-): The SSID is not assigned.
Clicking a row to select it opens the Change SSID window. Change SSID
