Description Item
For a Smart Tiers pool, DT is displayed.
For a Thin Provisioning Z pool, Mainframe THP is displayed.
For a Smart Tiers Z pool, Mainframe DT is displayed.
For a Snapshot pool, snapshot is displayed.
Displays the RAID level. If multiple RAID levels exist in a pool, this field indicates
as Mixed. RAID Level
Displays the hard disk drive type and RPM of the pool. If multiple drive types
or RPMs exist in a pool, this field indicates that drive types or RPMs are mixed. Drive Type/RPM
Displays whether the cache mode is enabled or disabled. For a configuration
other than external volume configuration, a hyphen (-) is displayed. Cache Mode
Displays the number of pool-VOLs set for the pool, and the maximum number
of pool-VOLs that can be set for the pool. Number of Pool VOLs
Displays the number of V-VOLs associated with the pool, and the maximum
number of V-VOLs that can be associated with the pool. Number of V-VOLs
For a Snapshot pool, a hyphen (-) is displayed.
Displays the number of primary volumes of the Snapshot pairs. When the
applicable volume does not exist, a hyphen (-) is displayed. Number of Primary VOLs
Displays the used and total V-VOL capacity. For a Snapshot pool, a hyphen (-)
is displayed along with the used and total V-VOL capacity. Pool Capacity (Used/Total)
Displays the used and total V-VOL capacity. For a Snapshot pool, a hyphen (-)
is displayed along with the used and total V-VOL capacity. V-VOL Capacity (Used/Total)
Displays the subscription (Rate of total V-VOL capacity associated with a pool
to the pool capacity/Subscription that is set). Subscription (Current/Limit)
For a Snapshot pool, a hyphen (-) is displayed for Current or Limit.
Displays the user-defined threshold (Warning/Depletion). User-Defined Threshold
(Warning/Depletion)
For a Thin Provisioning or Smart Tiers pool, as for the pool with only one of
the user definition threshold set, the system threshold (fixed at 80%) is enabled.
If the user-defined threshold is 80% or less, the value is displayed in the Warning
column. If the user-defined threshold is 81% or more, the value is displayed in
the Depletion column. In this case, the other column displays a hyphen (-).
For a Snapshot pool, a hyphen (-) is displayed for Depletion.
If Smart Tiers or Smart Tiers Z is enabled, Auto or Manual is displayed. If Smart
Tiers or Smart Tiers Z is disabled, a hyphen (-) is displayed. Tier Management
For a Snapshot pool, a hyphen (-) is displayed.
Displays the cycle of performance monitoring and tier relocation. If Smart Tiers
or Smart Tiers Z is disabled, a hyphen (-) is displayed. Cycle Time
Displays the time of starting and ending of performance monitoring. If Smart
Tiers or Smart Tiers Z is disabled, a hyphen (-) is displayed. Monitoring Period
Displays the monitoring mode that is set for the pool. If the continuous mode is
enabled, Continuous Mode is displayed. If the period mode is enabled, Period Monitoring Mode
Mode is displayed. If Smart Tiers or Smart Tiers Z is disabled, a hyphen (-) is
displayed.
Displays the status of pool monitoring. Monitoring Status
If the monitoring is being performed, In Progress is displayed. A hyphen (-) is
displayed other than this case.
284 Thin Provisioning and Smart Tiers GUI reference
