Description Item
Displays the Block LDEVs window. Block LDEVs*
Displays the Restore LDEVs window. Restore LDEVs*
Displays the Edit LDEVs window. Edit LDEVs*
Displays the Reclaim Zero Pages window. Reclaim Zero Pages*
Displays the Stop Reclaiming Zero Pages window. Stop Reclaiming Zero Pages*
Displays the View Tier Properties window. This window can open only for a
pool for which Smart Tiers is enabled. View Tier Properties*
Displays the View Pool Management Status window. View Pool Management Status*
For a Snapshot pool, nothing is displayed.
Displays the window for outputting table information. Export*
*Appears when you click More Actions.
Primary Volumes tab
If you select the Snapshot pool, this tab is displayed.
Description Item
Displays the combination of the LDKC, CU, and LDEV. LDEV ID
Clicking LDEV ID opens the LDEV Properties window.
Displays the LDEV name. LDEV Name
Displays information about the V-VOL status. Status
Normal: Normal status.
Blocked: Blocked.
Displays the emulation type. Emulation Type
Displays the used pool capacity. Used Pool Capacity
Displays the pool usage level. Pool Usage(%)
Displays the number of alternate paths. Number of Paths
Displays the CLPR. Displays in ID:CLPR form. CLPR
Displays the window for outputting table information. Export
Create Pools wizard
Create Pools window
Use this window to create new pools for Thin Provisioning or Snapshot.
CAUTION: When you create the Thin Provisioning or Thin Provisioning Z pool, if you specify
Any for RAID level to display the Select Pool VOLs window, external volumes with the cache mode
set to disabled are not displayed in the Available Pool Volumes table because they cannot coexist
with volumes of the other RAID levels:
When you select these volumes in the Select Pool VOLs window, specify a hyphen (-) for RAID level.
288 Thin Provisioning and Smart Tiers GUI reference
