Description Item
Displays the emulation type. Emulation Type
Displays the hard disk drive type and RPM. Drive Type/RPM
Displays the tier ID. For a Thin Provisioning, Thin Provisioning Z, or Snapshot
pool, a hyphen (-) is displayed. Tier ID
Displays the type of the LDEV. Provisioning Type
Basic: Internal volume.
External: External volume.
Displays the CLPR ID. CLPR
Displays whether the pool-VOL can be removed. For a Snapshot pool or while
the pool is being shrunk, a hyphen (-) is displayed. Shrinkable
Displays the resource group names and IDs of the LDEV. The ID is provided in
parentheses. Resource Group Name (ID)
Displays the Expand Pool window. Expand Pool
Displays the Shrink Pool window. Shrink Pool
Displays the Stop Shrinking Pools window. Stop Shrinking Pools
Displays the window for outputting table information. Export
Virtual Volumes tab
This tab is display unless you select a Snapshot pool,
Description Item
LDEV identifier, which is the combination of LDKC, CU, and LDEV. LDEV ID
Displays the LDEV name. LDEV Name
Displays information about the V-VOL status. Status
Normal: Normal status.
Blocked: Blocked.
Displays the emulation type. Emulation Type
Displays the V-VOL capacity. Capacity - Total
Displays the V-VOL used capacity. Capacity - Used
The displayed value Total might be larger than the displayed value Used due to
following reasons:
•
Used displays the used V-VOL capacity which is rounded up on each page.
•
If the emulation type is 3390-A, the used capacity of V-VOL includes the
capacity of control cylinders (7 Cyl is required per 1,113 Cyl).
Displays the V-VOL usage level. Capacity - Used(%)
Displays the number of alternate paths. A hyphen(-) is displayed for the Thin
Provisioning Z or Smart Tiers Z V-VOL. Number of Paths
Displays the CLPR ID. CLPR
Displays the tiering level of the tiering policy. Tiering Policy - Tiering Level
All: All tiers in the pool are used.
Level1: Level 1 is set to V-VOL.
286 Thin Provisioning and Smart Tiers GUI reference
