NOTE: Up to 1,024 volumes can be added including the volumes already in the pool.
When adding a volume to the pool for which Multi-Tier Pool is enabled, note the following:
•
Up to three values are allowed for Drive Type/RPM for the volume to be added.
•
For the volumes to be added to the same pool, you must have one RAID Level value for one
Drive Type/RPM.
Example: You cannot add a volume whose Drive Type/RPM is SAS/15k and whose RAID
Level is 5(3D+1P), and a volume whose Drive Type/RPM is SAS/15k and whose RAID Level
is 5(7D+1P) to the same pool.
When adding a volume to the pool for which Multi-Tier Pool is disabled, note the following:
•
Up to three values are allowed for Drive Type/RPM for the volume.
Remove button
When you select a row in Selected Pool Volumes table and click the Remove button, the selected
pool-VOL is removed from the Selected Pool Volumes table.
Selected Pool Volumes table
Description Item
Displays the LDEV identifier, which is the combination of LDKC, CU, and LDEV. LDEV ID
Displays the LDEV name. LDEV Name
Displays the pool-VOL capacity. Capacity
Displays the parity group ID. Parity Group ID
Displays the RAID level. RAID Level
Displays the hard disk drive type and RPM. Drive Type/RPM
Displays the emulation type. Emulation Type
314 Thin Provisioning and Smart Tiers GUI reference
