Transfer Profiles
Figure 86: Transfer profiles
To transfer an extracted data file, saved on the handheld, to a memory stick, follow these steps
1 From the ORION Profile Extraction menu, select
Transfer Profiles
Result: Saved (archived) Transfer Profiles are displayed.
2 Tap to select a file to transfer If you want to transfer
all the files, use the Select All button
Result: The Transfer button becomes active.
3 Insert a memory stick into the USB port on the
handheld Then tap Transfer
Result: The file(s) are transferred to the memory stick.
When the transfer is complete, the selected file(s) are
removed from the screen and the Transfer button
becomes inactive.
NOTE: N Transferred files are still available Tap Show
Archived to see the transferred files
Figure 87: Select file to transfer
Number of
selected files
Total number
of files
ORION PROFIlE ExTRAcTION
Page 53 April 2014 ORION® Endpoint Utility for Trimble® Ranger 3
