Profile Extraction Fields and Buttons
S/N Displays the serial number of the ORION Migratable endpoint
IR / RF Extract profile data via IR or RF Tap the box to select
Days Drop-down menu used to select the number of days for the profile extraction Available choices:
7, 14, 30, 60, All (90)
Read Res. Tap to see a list of test circles for the encoder
Oldest Reading The date and time of the oldest reading in the extracted data
Interval The reading interval at which the endpoint is set: 60 (every hour) or 15 (every quarter hour)
Quantity The number of interval reads extracted from the endpoint
Status(es) Displays any potential issues that require attention Example: tamper, no usage, etc
Change Interval Tap to change the reading interval for the endpoint A message asking for confirmation displays
before and after changing the interval All currently stored profile data is erased when the interval
is changed
Clear Endpoint Tap to erase the stored historical interval data for the endpoint
Save Saves the extracted data on the handheld The csv file can be viewed with the ORION Profile
Viewer software
A confirmation message displays to show where the file is saved on the handheld
The file location
path includes the endpoint serial number and the date and time
Example: \Program Files\Badger Field Applications\Mobile Read Net\ProfileExtraction\
LogFiles\30000264 20140205 115349 csv
Show Archived Tap to show previously transferred profile data files
The chart below shows the number of readings collected for meters set at 60 minute (hourly) intervals and at 15 minute
(quarter hourly) intervals:
Available Profile Data
Extraction Intervals
Hourly Reads:
1 Read per Hour
24 Reads per Day
15 Minute Reads:
4 Reads per Hour
96 Reads per Day
7 days 168 reads (24 x 7) 672 (96 x 7)
14 days 336 reads (24 x 14) 1344 (96 x 14)
30 days 720 reads (24 x 30) 2160 (96 x 22 5)
60 days 1440 reads (24 x 60) 2160 (96 x 22 5)
All/ 90 days 2160 reads (24 x 90) 2160 reads (96 x 22 5)
NOTE: N The ORION Migratable (or Fixed Network in mobile mode) water endpoint is capable of storing up to 90 days of
hourly interval data, or 2160 hourly reads If the account is set up to read every 15 minutes – 4 readings per hour –
the data extracted reflects four (4) readings per hour and reaches the maximum 2160 reads in 22 5 days
(90 days / 4 = 22 5 days)
ORION PROFIlE ExTRAcTION
Page 52 April 2014 ORION® Endpoint Utility for Trimble® Ranger 3
