Page 79: 1 about the dust-proof capability
69
7.Cleanroom Specification (RCP
CR-GRSS, RCP
CR-GRLS)
7. Cleanroom Specification (RCP2CR-GRSS, RCP2CR-GRLS)
7.1 About the Suction Amount
To use as cleanliness class 10, inside of the body must be vacuumed.
Connect an air piping on the 4mm-suction joint (provided at the customer side) to vacuum and perform
vacuuming for the amount shown below with a device such as a vacuum pump, a blower, or an ejector.
Recommend vacuum amount
10 NI/min
8. Dust-proof Specification (RCP2W-GRSS, RCP2W-GRLS)
8.1 About the Dust-proof Capability
Protective structure is IP50.
IP50: A structure where dust that can affect performance will not penetrate inside.
