1. Names of Gripper Parts

1.7

Medium Two-finger Type (RCP2-GRS/GRM)

Open/close screw

Side cover L

Left

Actuator cable

Frame

Finger L

Finger guide

Guide cover L

Right

Guide cover R

Finger R

Side cover R

Rear

Front
