43
4. Installation Method
[RCP2-GRHM]
[RCP2-GRHB]
4-M4, depth 6
4-M4, depth 6
depth 5
depth 5
Home
Home
Home
Home
Do not use the screw
holes at the center of
the finger.
Do not use the screw
holes at the center of
the finger.
33.5
42.5 39.5 39.5
39.5
33.5
6.5
6.5
33.5
