© 2005 Alamo Group Inc. Section 12 - 2
Maverick (NH TS-100A, 115A, 125A, 135A, Asy. Manl) 01/05
MAVERICK PRE-DELIVERY INSPECTION CHECKLIST
Pre-Operation Inspection: Check the following items before operating the unit to assure
that they are properly assembled. (See following page 1-4 for component location)
Saftey Equipment:
----- Operators Manual is with Unit.
----- The Safety Decals are installed as listed in the Assembly Manual.
----- Valve operation plate is installed.
----- Operators cage or Tractor Cab is in place.
----- Deflectors are installed on the Mower Head.
----- Tractor Rops or Cab with seatbels installed properly.
Frame and Boom: (NH TS-100A, 115A, 125A & 135A)
----- Axle Plate Bolts are torqued to 280 ft. lbs.
----- Boom Rest Axle Plate Bolts are torqued to 280 ft. lbs.
----- Front Rail Bolts are torqued to 425 ft. lbs.
----- Front Support Bolts at tractor are torqued to 355 ft. lbs.
----- Rear Rail Bolts torque to 425 ft lbs.
----- Rotator bolts torque to 120 ft. lbs.
----- All Welds inspected toinsure proper welds and locations.
Hydraulic System:
----- Oil Level in Hydraulic Tank is within the sight gauge.
----- Hose connections are tight.
----- Hoses do not have any kinks or twist in them.
----- Front Pump Shaft adapter bolts are tight..
----- Front Pump Shaft Coupler / Drive Shaft is lubricated and has an anti-seize compound
on the Splines of Pump and Shafts.
----- The Pump Drive Shaft has correct alignment.
----- Suction Hose has no leaks or kinks.
Rotary Mower Head:
----- Skid Shoe Bolts are torqued to 120 ft. lbs.
----- Spindle Housing Bolts are torqued to 400 ft. lbs.
----- The Spindle Housing is properly lubricated.
----- Motor Bolts are torqued to 120 ft. lbs.
----- Blade Carrier (Bar) Bolts torque to 400 ft. lbs.
----- Blade Bolts are torqued and the retainings Pins are in place.
----- Blades Swing freely.
Boom:
----- Boom Telesoping Bearings Adjusted completely inward.
----- All Hoses tightened and no leaks.
----- All hoses secured to where they will not rub, get pinched or hanging down where they may
catch on something.
----- All Decals installed
----- Pump Primed and Pressure adjusted if needed (only applys to Pump for Cylinder control.
