© 2004 Alamo Group Inc. 11 - 9
Maverick (NH TS-100A,115A, 125A, 135A Asy. Man) 01/05
02971789 Wheel Weight Kit: Consist of the following Item No.
Item Part No. Qty Description
1 02970758 1 WHEEL WEIGHT, 1400 LBS
2 02971569 3 WASHER, WHEEL WEIGHT
3 02971791 1 DRAWING, WHEEL WEIGHT INSTALLATION
4 02979603 3 BOLT, HEX HEAD 7/8”-NC X 16” PL GR 8 (4” OF THREAD)
5 00012200 3 LOCKWASHER, 7/8” PL STD
6 00012300 3 NUT, HEX 7/8”-NC
Wheel Weight Kit P/N 02971789 is in Mount Kit P/N 02982343
02976671 Auxillary Wheel Weight Kit: Consist of the following Item
No.
Item Part No. Qty Description
1 00012200 2 LOCKWASHER, 7/8” PL STD
2 00012300 2 NUT, HEX 7/8”-NC
3 00760266 2 BOLT, HEAX HEAD 7/8”-NC X 5-1/2” GR8
4 02976644 3 PLATE, WHEEL WELDMENT
Auxilary Wheel Weight Kit P/N 02976671 is in Mount Kit P/N 02982343
02980938 Fuel Tank: Consist of the following Item No.
Item Part No. Qty Description
1 00011100 3 FLAT WASHER, 7/8” PL STD
2 00015800 3 LOCKNUT, TOPLOCK 3/8”
3 00037200 2 LOCKNUT, 3/4”-NC
4 00001800 4 LOCKNUT, TOPLOCK 1/2”-NC PLB
5 02776600 4 BOLT, HEX HEAD 1/2”-13NC X 1-1/4" PL GR8
6 03200285 1 DECAL, WATCH YOUR STEP
7 00752405 2 BOLT, HEX HEAD 3/4”-NC X 5-1/2” PL GR8
8 108693 1 GAS CAP
9 02976633 1 WLDMT STEP
10 00753642 3 BOLT, HEX HEAD 3/8”-NC X 1-1/4” PL GR5
11 02980996 6 BOLT, SOCKET HEAD #10-24 X 1"
12 63121800 6 LOCKWASHER, #10 STD PL
13 31001000 6 FLATWASHER, 3/16” PL STD
14 02982198 1 WLDMT. FUEL TANK
15 02982206 1 WLDMT. FRONT BRACKET
16 02982207 1 WLDMT. REAR BRACKET
Replacement Fuel Tank Kit P/N 02980938 is in Mount Kit
P/N 02982343
Mounting Component ID
24 ft. Cab & 2wd
