Alamo TS-100A - Manual (Page 112)

© 2004 Alamo Group Inc. 11 - 2
Maverick (NH TS-100A,115A, 125A, 135A Asy. Man) 01/05
Mounting Specifications
New Holland TS-100A / 115A / 125A / 135A Cab/2&4wd
As of 01-05-05
10.00-16SL (F-2) Min / 11.00-16SL (F-2M) Max 2wd Front Tire
12.4-24 (R-1) Min / 14.9-24 (R-1W) Max 4wd Front Tire
18.4-30 (R-1) Min / 18.4-34 (R-1W) Max Rear Tire
Mount Kits:
24' Maverick 2wd* Mount Kit ………………........ 02982343 (Page 11-7 thru 11-10)
24' Maverick 4wd Mount Kit …………………...... 02982341 (Page 11-11 thru 11-14)
30' Maverick 4wd** Mount Kit ……………...…... 02981892 (Page 11-15 thru 11-18)
Common pParts Box:
Common Parts Box................. ……………..……..02981781 (Page 11-4 thru 11-6)
(Common Parts Box shipped with all models no matter which boom or tractor model)
* 2wd tractors must be equipped with heavy duty, eight bolt front wheel hubs & spindles
** 30' Maverick booms must be mounted on 4wd tractors only due to front axle spindle
loading.
Options:
Extra Maverick Installation Manual …………..…… 02982279
Standard Features:
1. Modified exhaust pipe for boom transport clearance.
2. Replacement arm rest with joystick console.
3. Neapco style driveline with double U-joints.
4. 1400# wheel weight plus 408# auxiliary weight kit.
5. Right hand replacement Lexan door 3/8" Lexan replacement door (right side only). (See Figure 4)
6. 51 gallon replacement fuel tank.
7. ~10" of ground clearance with the min. tire size shown.
Restriction Notes:
1. Exhaust must be modified for clearance. (See Figure 1)
2. Battery box must be relocated by installing battery relocation brackets . (See Figure 3)
3. Factory Seat Arm rest (RH Side) will be replaced by metal arm rest joystick mount. (See Figure 2)
4. Electronic components and display modules will have to be mounted in cab. (See Figure 5), these
must be mounted inside Cab to keep them protected from weather.
5. Display must be set to correct operating parameters before unit will function (See Figure 6).
