Component identification – Alamo TS-100A User Manual
Page 144
© 2004 Alamo Group Inc.
11 - 34
Maverick (NH TS-100A,115A, 125A, 135A Asy. Man) 01/05
P/N 02976633 LH Side Step Wldmnt
P/N 02980694 LH Rear Top Axle strap
Component Identification
P/N 02981168 Center Section Under Mount Frame Wldmnt
Rear View
Front of
Tractor
LH Side of
Tractor
RH Side
of Tractor
Rear of
Tractor
Install with these
openings to front
of tractor
