© 2004 Alamo Group Inc.

11 - 10

Maverick (NH TS-100A,115A, 125A, 135A Asy. Man) 01/05

02980888

Lexan Door kit, RH Door : Consist of the following Item No.

Item

Part No.

Qty

Description

1

02980803

1

LEXAN DOOR, NEW HOLLAND TS-A

2

02980889

1

TRIM PUSH ON WEATHER SEAL 199"

3

00021900

2

BOLT, HEX HEAD 5/16”-NC X 1-3/4” PL GR5

4

00750940

4

LOCKNUT , TOPLOCK 5/16”-NC PLB

5

02766400

2

BOLT, HEX HEAD 5/16”-NC X 1-1/2”

6

02981016

1

CARTON, NH TS-A LEXAN DOOR

7

02981035

1

INSERT,LEXAN DOOR INSTALLATION

Lexan Door Kit P/N 02980888 is in Mount Kit P/N 02982343

02980916

Exhaust Relocation Kit : Consist of the following Item No.

Item

Part No.

Qty

Description

1

02980917

1

PIPE, EXHAUST NH TS115A

2

02980728

3

BOLT, HEX HEAD M12-P1.75 X 30mm PL GR10.9

3

701513C

3

M12 FLATWASHER

4

00754566

3

LOCKWASHER, 12MM

5

02980933

1

WLDMT. EXHAUST BRACKET

6

02959132

2

CLAMP, 3 1/2HD MUFFLER CLAMP

Exhaust Reloctaion Kit P/N 02980916 is in Component Box P/N 02982344
which is in Mount Kit P/N 02982343

02981750

Battery Relocation Kit : Consist of the following Item No.

Item

Part No.

Qty

Description

1

02980917

1

PIPE, EXHAUST NH TS115A

1

02981725

1

WLDMT BATTERY BRACKET

2

00011400

3

BOLT, HEX HEAD 3/8”-NC X 1”

3

00012101

3

LOCKWASHER, 3/8” PL

4

00013901

3

NUT, HEX 3/8”-NC PL

Battery Reloctaion Kit P/N 02981750 is in Component Box P/N 02982344
which is in Mount Kit P/N 02982343

Mounting Component ID

24 ft. Cab & 2wd
