Special Torque Specifications (Rotary Heads)

Motor to Spindle Housing........................................................... 100 ft. lbs.
Spindle to Deck..........................................................................425 ft. lbs.
Spindle to Adjusting Nut (Bearing Preload)............................... 25 in. lbs. Rolling Torque
Blade Bar Leaf Bolts (

1-1/4" Bolts)....................................... 2000 ft. lbs.

Blade Bar to Spindle Bolts......................................................... 400 ft. lbs.
Blade Bolts................................................................................ 400 ft. lbs.
Motor Plate.............................................................................

See Set Up Instructions

11.TORQUE VALUES - BOLTS:

Recommended Torque, Ft. lbs. & (Nm)

IMPORTANT! Listed below IS BOLT TORQUE and NOT APPLICATION TORQUE, Component
Application Torque will vary depending on what is bolted down and the type material (Metal) that is being
bolted together. Thread condition and lubrication will vary Torque settings.

Bolt

Dia.
m m

4.8

8.8

10.9

6
8
10
12
14
16
18
20
22
24
27
30
33
36

5

(*6)

11

(*15)

20

(*27)

37

(*50)

60

(*81)

92

(*124)

118

(*159)

160

(*217)

215

(*291)

285

(*386)

450

(*610)

600

(*813)

800

(*1084)

900

(*1220)

7

(*9)

20

(*27)

40

(*54)

70

(*95)

100

(*135)

155

(*210)

216

(*292)

270

(*366)

330

(*447)

500

(*678)

875

(*1186)

1200

(*1627)

1600

(*2169)

2100

(*2847)

12

(*16)

25

(*33)

58

(*78)

105

(*142)

140

(*189)

200

(*271)

280

(*379)

355

(*481)

430

(*583)

700

(*949)

1000

(*1355)

1700

(*2304)

2300

(*3118)

3000

(*4067)

ALWAYS CHECK MARKINGS ON TOP OF BOLT HEAD OR OTHER BOLT DESCRIPTIONS

Plain Head

3 Dashes

6 Dashes

Bolt

Dia.

inch

2 (B)

5 (D)

8 (F)

1/4
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8
1
1-1/8
1-1/4

Not Used
Not Used
Not Used

35

(*47)

55

(*75)

75

(*102)

105

(*142)

185

(*251)

160

(*217)

250

(*339)

330

(*447)

480

(*651)

10

(*14)

20

(*27)

35

(*47)

55

(*75)

85

(*115)

130

(*176)

170

(*230)

300

(*407)

445

(*603)

670

(*908)

910

(*1234)

1250

(*1695)

14

(*19)

30

(*41)

50

(*68)

80

(*108)

120

(*163)

175

(*230)

240

(*325)

425

(*576)

685

(*929)

1030

(*1396)

1460

(*1979)

2060

(*2793)

Inche Sizes

Metric Sizes

ft. lbs

(*N-M)

ft. lbs

(*N-M)

ft. lbs

(*N-M)

ft. lbs

(*N-M)

ft. lbs

(*N-M)

ft. lbs

(*N-M)

9.

HOSE END FITTING TORQUE SPECS:

Hose End Type:

37 Degree Angle End Steel Hose End Fittings*

Dash

Nominal Cyl.

Torque

Torque

Size

Size (in.)

in. lbs.

ft .lbs.

-4

1/4"

140

12

-6

3/8"

230

19

-8

1/2"

450

38

-10

5/8"

650

54

-12

3/4"

900

75

-16

1"

1200

100

-20

1-1/4"

1600

133

-24

1-1/2"

2000

167

-32

2"

2800

233

* Straight Threads do not always seal better when higher torques are used. Too much torque causes
distortion and may lead to leakage. DO NOT over torque fittings and DO NOT allow any contaminants
to enter system through fittings when installing them.

SPECIFICATIONS - MAVERICK
