Page 117: 24 foot maverick 2wd* mount kit
© 2004 Alamo Group Inc.
11 - 7
Maverick (NH TS-100A,115A, 125A, 135A Asy. Man) 01/05
New Holland
TS-100A / 115A / 125A / 135A
Cab & 2wd
Mounting Component ID
24 ft.
Cab & 2wd
IMPORTANT NOTICE:
The following Part / Assembly Numbers are for reference and
should not be ordered as replacement parts, unless all the components in that assembly are
wanted. These will break down to bills of material of the components. Some of numbers listed are
NOT individual Parts but complete assemblies and/or box of assemblies. Check before ordering.
24 foot Maverick 2wd* Mount Kit
(* 2wd tractors must be equipped with heavy duty, eight bolt front wheel hubs & spindles)
02982343 Maverick Mount Kit -
NH TS-100A/115A/125A/135A Cab 2 wd:
Consist of the Following Items
Item Part No.
Qty Description
1.
02980888
1
LEXAN REPLACEMENT DOOR KIT, RH SIDE
2.
02971789
1
WHEEL WEIGHT KIT, 1400 LBS.
3.
02976671
1
AUXILLARY WHEEL WEIGHT KIT 408LBS.
4.
02980938
1
REPLACEMENT FUEL TANK KIT
5.
02982005
1
RAIL WELDMENT, RH REAR
6.
02982006
1
RAIL WELDMENT, LH REAR
7.
02982014
1
RAIL WELDMENT, RH FRONT
8.
02982015
1
RAIL WELDMENT, LH FRONT
9.
02982314
1
BOOM REST WELDMENT
10.
02982344
1
COMPONENT BOX
02982344 Component Box: Consist of the following Item No.
Item
Part No.
Qty
Description
1
02980699
1
PULLEY ADAPTER NH TS-A
2
02980719
1
ASSY, TS-A PUMP MOUNT W/COVER
3
02980694
1
PLATE, BOOM REST STABILIZER
4
02980916
1
KIT, EXHAUST RELOCATION TS115A
5
02981750
1
KIT, BATTERY RELOCATION
6
02982000
1
DRIVELINE, MODIFIED 02975257A
7
02982157
1
HOSE BUNDLE 6 CYL MAVERICK
Continued next page
