23
Technicaldata
6.8. Factory settings of the positioner
Functions can be activated via DIP switches:
Function Parameter Value
CUTOFF Sealing function below
Sealing function above 2 %
98 %
CHARACT Select characteristic FREE 5)
DIR.CMD Effective direction set-point value rise
Table 4: Factory settings - Functions I
Functions can be activated via communications software:
Function Parameter Value
INPUT Set-point value input 4 ... 20 mA
DIR.ACTUATOR Effective direction actual value rise
SPLITRANGE
Function deactivated Signal split range below
Signal split range above 0 %
100 %
X.LIMIT
Function deactivated Stroke limit below
Stroke limit above 0 %
100 %
X.TIME
Function deactivated Actuating time Open
Actuating time Closed (1 s) values determined by X.TUNE
(1 s) values determined by X.TUNE
After implementation of RESET: 1 s
X.CONTROL Deadband
Open amplification factor
Close amplification factor 1,0 %
(1) values determined by
X.TUNE
(1) values determined by X.TUNE
After implementation of RESET: 1
SAFE POSITION Safety position 0 %
SIGNAL ERROR
Function deactivated Sensor break detection set-point value OFF
BINARY INPUT Binary input function
Operating principle of binary input Safety position
Normally open
OUTPUT
(optional) Norm signal output: Parameter
Norm signal output: Type Position
4 – 20 mA
Table 5: Factory settings Functions II
5)
Without change to the settings via the communications software a linear characteristic is stored in FREE.
