Questionable Status Group
Same as Channel Status Group
Standard Event Status Group
Bit
Signal Meaning
0
OPC
Operation Complete. The load has completed all pending operations. *OPC
must be programmed for this bit to be set when pending operations are
complete.
2
QYE
Query Error. The output queue was read with no data present or the data was
lost. Errors in the range of 499 through 400 can set this bit.
3
DDE
Device-Dependent Error. Memory was lost or self-test failed. Errors in the
range of 399 through 300 can set this bit.
4
EXE
Execution Error. A command parameter was outside its legal range,
inconsistent with the load's operation, or prevented from executing because
of an operating condition. Errors in the range of 299 through 200 can set this
bit.
5
CME
Command Error. A syntax or semantic error has occurred or the load received
a
set this bit.
7
PON
Power-On. The unit has been turned off and then on since this bit was last
read.
Status Byte and Service Request Enable Registers
Bit
Signal Meaning
0
CSUM Channel Summary. Indicates if an enabled channel event has occurred.
2
EAV
Error Available Summary. Indicates if the Error Queue contains data.
3
QUES
Questionable Status Summary. Indicates if an enabled questionable event has
occurred.
4
MAV
Message Available Summary. Indicates if the Output Queue contains data.
5
ESB
Event Status Summary. Indicates if an enabled standard event has occurred.
6
RQS/MSS
Request Service. During a serial poll, RQS is returned and cleared.
Master Status Summary. For an *STB? query, MSS is returned without being
cleared.
7
OPER Operation Status Summary. Indicates if an operation event has occurred.
