55
Displayed Alarm /
Warning
Device Description Recommended Actions
SCM Alarms
Containment Not Learned SCM The learning process has not been
completed.
Refer to Secondary Containment Monitoring Installation and User’s
Guide 000-0528 for more information.
Containment Program
Error Detected
SCM An error has been detected in the
containment programming.
Containment Program
Error Warning
SCM An error has been detected in the
containment programming
Containment Pump
Request Ignored
Engineering The containment called for the
STP to turn on but has not seen an
increase in vacuum level.
Failed to Hold Vacuum SCM The rate of vacuum decay faster
than the learned rate.
Failed to Reach Target
Vacuum
SCM 6”hg could not be reached in the
learned time.
Low Vacuum SCM The vacuum level has dropped
below 1”hg.
Low Vacuum And Pump
Request Ignored
Engineering Low vacuum level due to Pump
Request Ignored.
Not Configured SCM Containment programming has not
been completed
Unstable Vacuum SCM Vacuum level is fluctuating at a
rate that is FFSsistent with the
learned parameters.
Vacuum Sensor Failed SCM The 4-20mA vacuum transducer
has failed and is no longer
detected
Vacuum Too High SCM The vacuum level has reached
above 10”hg
Wire Sensor Alarms
Displayed Alarm /
Warning
Device Description Recommended Actions
SN2 Sensor On ChannelSN2 Sensor shows alarm status. Inspect location for presence of liquid. In the case of a leak, follow
site policy procedures. If no liquid is present, and alarm still exists,
sensor may be tripped on error. Check wiring continuity from sensor
to console. Test sensor at console, trip sensor on purpose. Verify
console terminal wiring. If issue still exists, inspect wiring to sensor.
Contact Franklin Fueling Systems’ Technical Services for support.
SN2 Fuse Blown ChannelSN2 2-Wire Sensor Module fuse blown
due to unknown causes.
The fuses on the Sensor boards are non-serviceable per UL listing
standards. The module must be replaced if the fuse is blown.
SN3 Data Error ChannelSN3 Console has received erroneous
data from sensor.
Check wiring continuity from sensor to console. Test sensor at
console, trip sensor on purpose. Verify console terminal wiring. If
issue still exists, inspect wiring to sensor. If the condition still exists,
contact Franklin Fueling Systems’ Technical Services for support.
SN3 Dry Well ChannelSN3 Monitoring well is dry. Visually verify that the alarm is correct.
SN3 Fuse Blown ChannelSN3 3-Wire Sensor Module fuse blown
due to unknown causes.
The fuses on the Sensor boards are non-serviceable per UL listing
standards. The module must be replaced if the fuse is blown.
SN3 High Brine ChannelSN3 Brine solution has tripped high
level brine sensor.
Verify actual level of solution and sensor installed location.
SN3 Low Brine ChannelSN3 Brine solution has tripped low level
brine sensor.
Verify brine level and sensor location.
SN3 ID Error ChannelSN3 Discriminating sensor is given an
improper ID.
Verify sensor programming and Auto configuration.
SN3 No Signal ChannelSN3 Console is not receiving data from
a discriminating sensor.
Verify programming of sensor type and wiring connection.
SN3 Product ChannelSN3 Discriminating sensor has
detected product present at
location.
Visually inspect location carefully for presence of liquid. In the case of
a leak, follow site policy procedures. If no liquid is present, and alarm
still exists, sensor may be tripped on error. Check wiring continuity
from sensor to console.
