5-19 MLC 226 IP Series • SIS Programming and Control
PRELIMINAR
Y
Command/r
esponse table for SIS commands (continued)
Command
ASCII (T
elnet)
(host to switcher)
URL Encoded (W
eb)
(host to switcher)
Response (switcher to host)
Additional description
Query updated fi
rmwar
e
version
4Q
4Q
X1!
(kernel version–model description–date time of upload)
]
or
V
er04*
X1!
(kernel version–model description–date time of upload)
]
Use this command to fi
nd out which version
of the fi
rmwar
e, if any
, was uploaded into
the contr
oller after it left the factory
Example:
4Q
4Q
1.01*(1.31-MLC226 -Mon, 28 Feb 2005 23:16:55 GMT)
]
In this example the curr
ent fi
rmwar
e
version
is 1.01, the IP
Link kernel version is 1.31, for
the MLC 226 IP
, dated 28 Febr
uary
, 2005.
Query FPGA
version
32Q
32Q
X1!
]
Show the fi
eld-pr
ogrammable gate array
(FPGA) fi
rmwar
e version to two decimal
places (x.xx).
Request the MLC’s part number
N
N
60-600-00
]
60-818-00
]
or
Pno60-600-00
]
60-818-00
]
Show the MLC’s part #.
Request A/V
input
number
I
I
Chn
X20)
]
Show which input is active (selected).
X20)
is the input number
. The MLC
responds with an E14 err
or if no input
buttons ar
e set up for fi
rmwar
e
contr
ol
(input switching).
Request the model name
1I
1I
MLC 226 IP
]
or
Inf01*MLC 226 IP
]
MLC 226 IP
Request the model description
2I
2I
MLC 226 w/ IP
]
or
Inf02*MLC 226 w/ IP
]
MLC 226 with IP
contr
ol.
Request system memory usage
3I
3I
# bytes used out of # of kbytes
]
or
Inf03*# bytes used out of # of kbytes
]
Show amount of memory used and total available memory for system operations.
Request user memory usage
4I
4I
# bytes used out of # of kbytes
]
or
Inf04*# bytes used out of # of kbytes
]
Show amount of user memory used and total available user memory
.
Example:
4I
4I
217856 Bytes Used out of 7232 KBytes
