Page 146: Reference material, cont’d
Reference Material, cont’d
MLC 226 IP Series • Reference Material
A-10
PRELIMINAR
Y
Cut-out Templates
This section includes templates for the MLC 226 IP, MLC 226 IP AAP, and the
MLC 226 L. Templates for MLM 226 Series faceplates are available in the MLM 226
Faceplates Installation Guide, which you can download from http://www.extron.com.
To install an MLC 226 IP
directly into furniture,
cut along this line.
Top Panel
2.9"
(7.4 cm)
5.4"
(13.7 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
Location of
MLC 226 IP
MLC 226 IP
Cut-Out Template for Extron's
4.50" (11.43 cm)
6.40"
(16.26 cm)
PRINT TEMPLATE AT 100%.
