Reference Material, cont’d
MLC 226 IP Series • Reference Material
A-12
PRELIMINAR
Y
MLC 226 IP L
Cut-Out Template for Extron's
6.50"
(16.51 cm)
To install an
MLC 226 IP L
directly into
furniture, cut
along this line.
Top Panel
3.15"
(8.00 cm)
Location of
MLC 226 IP
2.9"
(7.4 cm)
5.4"
(13.7 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
PRINT TEMPLATE AT 100%.
