SIS ™ Programming and Control, cont’d
MLC 226 IP Series • SIS Programming and Control 5-16
PRELIMINAR
Y
Command/r
esponse table for SIS commands (continued)
Command
ASCII (T
elnet)
(host to switcher)
URL Encoded (W
eb)
(host to switcher)
Response (switcher to host)
Additional description
Ether
net data port confi
guration and use
Set global IP
port
timeout period
24
E
1*
X6(
TC
}
W1%2A
X6(
TC
|
Pti 1*
X6(
]
The global port timeout is the default timeout period for all T
elnet sessions.
X6(
= IP
connection timeout period in
seconds. Each step is specifi
ed in 10-second
intervals (1 - 65000, default = 30 = 300 seconds). If no data is r
eceived during the
specifi
ed period, the Ethernet connection
closes. Responses ar
e r
eturned with leading
zer
os.
This timeout period is applicable only when the MLC is connected via Ethernet, and you must be logged in as an administrator to change this setting.
V
iew global IP
port
timeout period
E
1TC
}
W1TC
|
X6(
]
Set curr
ent port’s timeout
period
13, 24
E
0*
X6(
TC
}
W0%2A
X6(
TC
|
Pti 0*
X6(
]
The curr
ent port timeout period applies
to the curr
ently open T
elnet session only
.
When you start another T
elnet session, it
uses the default global port timeout period.
X6(
= timeout period in seconds. See
the description above. This variable is applicable only when the MLC is connected via Ethernet. If the MLC is connected via RS-232 pr
otocol, only the global timeout
commands apply
, and any commands
involving
X6(
r
eturn the E13 err
or r
esponse.
V
iew curr
ent port’s
timeout period
13
E
0TC
}
W0TC
|
X6(
]
