5-11 MLC 226 IP Series • SIS Programming and Control
PRELIMINAR
Y
Command/r
esponse table for SIS commands (continued)
Command
ASCII (T
elnet)
(host to switcher)
URL Encoded (W
eb)
(host to switcher)
Response (switcher to host)
Additional description
Set lamp hours status for 1 lamp
24
X20%
*6S
X20%
%2A
6S
Lhr*
X20%
]
X20%
repr
esents the fi
ve-digit
numeric
value for elapsed lamp use hours, and it is used by script to determine the number sent in r
esponse to the “view lamp hours”
command (6S).
24
= The MLC r
esponds with an E24 err
or
(privilege violation) if the connected user is not logged in at administrator security level.
Set lamp hours status for 2 lamps
24
X20%
*
X20%
*6S
X20%
%2A
X20%
%2A
6S
Lhr*
X20%
*
X20%]
V
iew connection status
7S
7S
X21^]
This command lets you know whether the MLC’s scripts have determined if the display is still connected to the MLC.
X21^
= 0 (disconnected), 1 (connected), or 2
(unknown).
Set display connection status
24
X21^
*7S
X21^
%2A
7S
Pcs
X21^]
This command is used to r
eset the
pr
ojector/display connection status fl
ag
(
X21^
) used by scripts.
0 = pr
ojector not connected.
1 = pr
ojector is connected.
2 = undetermined status.
V
iew power sensor status
8S
8S
X21#]
If the MLC is connected to an Extr
on Power
Sensor that monitors the pr
ojector/display
,
this tells you whether the display is still power
ed on.
X21#
is as follows:
00 = power sensor is connected and is not sensing pr
ojector power
.
01 = power sensor is connected and sensing pr
ojector power
.
02 = sensor is disconnected or sensor is connected but sensitivity is too high.
View power sensor signal pin status
9S
9S
X21$]
Power sensor signal pin status (
X21$
)
:
00 = voltage is low
.
01 = voltage is high The r
esponse includes leading zer
os.
V
iew all voltage and
temperatur
e status
11
S
11
S
responses fr
om commands
12S
•
13S
•
14S
•
15S
•16S•20S
]
V
iew all voltages and the MLC’s internal
temperatur
e at once.
V
iew +12 V power supply
voltage
12S
12S
+
X20^]
Display the operating voltage of the MLC’s power input.
X20^
= voltage in volts.
