SIS ™ Programming and Control, cont’d
MLC 226 IP Series • SIS Programming and Control 5-38
PRELIMINAR
Y
Command/response table for special function SIS commands, continued
Command ASCII
Command
(host to MLC)
Response
(MLC to host)
X?
values
and additional descriptions
Button control
Set slave map 24
X?
*3
Y?
# SlaveMap
Y?
*
X? ]
This command associates an
MLC input button with a specifi c
input on a connnected switcher.
X?
is the actual input channel
(including inputs on a slaved
switcher) to select when button
Y?
is pressed. The values for
these variables are shown at left.
Default: X? = Y?
00 = input 0
01 = input 1
02 = input 2
...
98 = input 98
99 = input 99
1 = input button 1
2 = input button 2
3 = input button 3
4 = input button 4
5 = input button 5
6 = input button 6
X? Y? values values
Example: 6*34# SlaveMap4*6
]
Map input 6 (an input on a
slaved switcher) to the MLC’s
input button 4. When button
4 is pressed, the A/V system
switches to input 6, and any
instructions (DVD or VCR
control commands, for example)
associated with input button 4
on the MLC are executed.
Set and trigger a button press
repeat
X?
*
Y?
*45 # RptRate*
X?
*
Y?]
This command tells the MLC to
repeat a specifi c button’s press
commands at a fi xed interval (a
set frequency).
X?
= the number of the button/
switch (1 - 128). See the
diagrams on pages 5-36 and
5-37.
Y?
is the repeat interval: 0 to
65535, in 20 ms steps.
1 = 20 ms, 2 = 40 ms, 3 = 60 ms,...
65535 = 1,310,700 ms = 21.845
minutes.
If
Y?
= 0, the MLC stops
repeating the selected button’s
commands.
Example:
9*850*45# RptRate*9*850
]
The commands associated
with the input 1 button press
are executed every 850x20 ms
(= 17,000 ms = 17 seconds) until
the repeat rate for that button is
set to 0 (“cleared”).
N The button repeat SIS command (
X?
*
Y?
*45 #) must be entered each time you want to have a button press trigger
repeated command releases. Also, only one button at a time can be set to repeat: multiple buttons can not be in repeat
mode simultaneously.
N The Repeat Rate... feature found in Global Confi gurator is based on this command. However, through scripting the
MLC sets the repeat mode to on in response to a specifi c button press, and it sets the repeat mode to 0 when the button
is released or input is no longer selected.
Query button repeat rate status 45#
X?
*
Y?]
See the variables for the
command shown above.
Clear (turn off) the button repeat 24 0*0*45# RptRate*000*00000
]
This command clears the button
repeat setting and turns off the
button repeat function.
