Preliminar y, Programming and control, cont’d – Extron Electronics MLC 226 IP Series Installation User Manual
Page 90
SIS
™
Programming and Control, cont’d
MLC 226 IP Series • SIS Programming and Control
5-12
PRELIMINAR
Y
Command/r
esponse table for SIS commands (continued)
Command
ASCII (T
elnet)
(host to switcher)
URL Encoded (W
eb)
(host to switcher)
Response
(switcher to host)
Additional description
V
iew +5 V IR r
eceiver port
voltage
13S
13S
+
X20^]
V
iew +3.3 V IP
Link/FPGA
voltage
14S
14S
+
X20^]
V
iew +1.5 V FPGA
voltage
15S
15S
+
X20^]
V
iew -10 V IR/Serial bus voltage
16S
16S
-
X20^]
Display the operating voltage for the IR/
Serial and pr
ojector ports.
V
iew internal temperatur
e status
20S
20S
X20&]
Display the internal operating temperatur
e.
X20&
= temperatur
e in degr
ees Celsius (the
response is 3 digits including leading zer
os).
