Installation, cont’d
MLC 226 IP Series • Installation 2-16
PRELIMINAR
Y
Pinout Guide
The illustration below summarizes the pin assignments of all of the MLC’s bottom
panel connectors that are covered in detail on pages 2-5 to 2-14.
A B C D E
DI
S
PLA
Y
R
S
-2
3 2/IR
R
S -2
3 2 12V
CM/IR/
S
CP
A B C D E
ML
S
PWR
AB
T x / I R
R x
G RO U N D
P W R S N S
G RO U N D
+ 1 2 V O U T
Rx
Tx
GROUND
GROUND
+12V IN
+12V OUT
GROUND
CONT MOD
IR IN
SCP COM
NORMALL
Y OPEN
1 2 COMMON
COMMON
COMMON
GROUND
Tx/IR
Tx/IR
Tx/IR
GROUND
GROUND
A
RELA
Y
S
IR/
S
ERIAL OUT
3
4
B
5 6 CA
B
C
MLC 226 IP
Bottom Panel
Common
Relay 1
Relay 2
To / from control equipment
(screen control motors, lights, etc.)
Ground ( )
Transmit (Tx)
Receive (Rx)
To an optional Extron switcher
From an external 12 VDC, 1 A (max.) power supply
Ground ( )
Receive (Rx)
Transmit (Tx)
To a projector or display
To an Extron
Display
Power Sensor
OR
+12 VDC
Ground ( )
Power sense
To an IR Emitter, IR Broadcaster,
or IR or serial (RS-232) controllable device
Ground ( )
+12 VDC input
SCP communication (IR)
Modulated IR (for IR Link or IRL 20)
Ground ( )
IRCM, ACM, RCM
+12 VDC
Digital
input
Ground
Signal (IR)
To / from optional Extron
control modules, IR Link IR
repeater, or SCP control pads
Mounting the MLC
Once the system has been cabled, confi gured (see chapter 4), and tested, the
controller can be installed in the wall, furniture, equipment rack, or Euro Channel.
DISPLAY
MLC 226 IP
1 2 3
4 5 6
VOLUME
CONFIG IR
ON OFF PIC
MUTE
LIGHT
OFF
DOC
CAM
VCR DVD
LAPTOP PC
AUTO
2
1
2
1
2
1
2
1
a
Mounting screws (4) — Use these to attach the MLC to a wall, furniture, or
other mounting surface.
b
Faceplate attachment screws (4) — Do not remove these screws during or
after mounting. They attach the faceplate to the MLC unit. Removing these
screws during or after mounting will cause the MLC to detach, and it may
then fall down into the wall or furniture.
