SIS ™ Programming and Control, cont’d
MLC 226 IP Series • SIS Programming and Control 5-6
PRELIMINAR
Y
in March and ends the fi rst Sunday in
November. DST should be turned off in
Hawaii, American Samoa, Guam, Puerto
Rico, the Virgin Islands, the eastern time
zone portion of the state of Indiana, and
the state of Arizona (excluding the Navajo
Nation).
2 = Europe
on – begins on the last Sunday
in March, ends on the last Sunday in
October. DST should be turned off for
Iceland.
X3%
= Event number, range = 0 - 99
(valid only while events are running)
X4)
= I/O mode
0 = input
1 = output (digital I/O on 9-pin D
connector only)
2
= input and pull-up resistor
(digital I/O on 9-pin D connector only)
3
= output and pull-up resistor (digital
I/O on 9-pin D connector only)
8
= power sensor digital input
X4!
= Password to display on screen (response to
password query or set). When the MLC
connects to a host device via RS-232, the
password (
X3#
), itself, is the response.
When the connection is via IP,
X4!
is 4
asterisks (****) if a password has been
assigned, or it is an empty fi eld ( ) if a
password hasn’t been assigned.
X4#
= I/O state
0 = off
1 = on
X4%
= E-mail event number or mailbox (1 - 64). The
response is two digits with a leading zero.
X4^
= E-mail recipient’s address (e.g.,
[email protected]) for the person to whom
messages will be sent. The e-mail address
has a 31 character maximum.
X4&
= Name (numeral) of e-mail fi le to be sent
X4(
= Default name: a combination of the model
name and the last 3 pairs of the MLC’s
MAC address (e.g., MLC-226-IP-00-02-3D)
X5@
= Connection’s security level
11 = user
12 = administrator
X5&
= IR playback fi le number (0 to 99) (no
extension) The response includes leading
zeros.
X5*
= IR playback function number (1 to 137) The
response includes leading zeros. IR
function numbers 0 and 127 or higher can
return information only.
0 = return all data
129 = manufacturer
130 = model
131 = class
132 = remote
133 = creation date
134 = comments
137 = user fi le name (a descriptive name
the user/installer gave the fi le).
X5(
= IR playback mode
0 = play once
1 = play continuously
X2!
= Parameter (#L or #D) to set either the Length
of message to receive or the Delimiter
value. # = byte count (for L) or
# = a single ASCII character expressed in
decimal form (for D).
The parameter is case sensitive; you must
use capital D or capital L.
Byte count # can be from 0 to 32767,
default = 0.
The ASCII decimal # can be from 0 to
00255, default = 00000L.
Examples:
A 3-byte length = 3L.
A delimiter of ASCII 0A = 10D.
The response from the MLC includes
leading zeros.
X2@
= Verbose/response mode status:
0 = clear/none, default for Telnet
connections; responses are not echoed to
the host
1
= verbose mode is on, default for RS-232
host control; responses are echoed to the
host and displayed to the user
2
= send tagged responses for queries
3 = verbose mode is on and tagged
responses are sent for queries
N If tagged responses are enabled, all read
commands return the constant string + data,
the same as for setting a value. For example,
for
E
CN
}
, the response is Ipn•
X1@ ]
rather than just the data.
X2#
= Priority status for receiving timeouts:
0 = use send data string command
parameters (0 = default)
1
= use confi gure receive timeout command
parameters
X2%
= Baud rate: 300, 600, 1200, 1800, 2400, 3600,
4800, 7200, 9600, 14400, 19200, 28800,
38400, 57600, or 115200
X2^
= Parity (only the fi rst letter is needed):
O dd
E ven
N one (default)
M ark
S pace
X2&
= Data bits: 7, 8 (default = 8)
X2*
= Stop bits: 1, 2 (default = 1)
X3#
= Password (minimum length = 4 characters,
maximum length = 12 characters,
no special characters are allowed)
N A user password cannot be assigned if no
administrator password exists; the E14 error
code will be returned. If the administrator
password is cleared, then the user password is
also removed.
X3$
= Daylight saving time (DST) is a region-
specifi c 1-hour offset that begins in spring
and ends in fall.
0 = off/ignore
1 = USA
on – traditionally starts on the
fi rst Sunday of April at 2 am and ends at
2 am on the last Sunday of October. For
example, time in California is GMT -8:00
from April to October and GMT -7:00
from November to March. However, in
2007 DST starts on the second Sunday
