USERS MANUAL
CHATTER™ DATA LOGGER
93
Setup
Use this pane to set the way each of the four
Instrument Net inputs will operate.
See below for a detailed description of each
part in this pane.
Signal name
Select an existing signal name or enter a new signal name.
The signal name will act as an identifier for this input. It is inserted into any SMS messages and e-mails sent
from this Instrument Net input.
Additional information:
Signal names explained
Unit type
Select an existing unit type or select an empty position in the list and enter a new unit type.
The unit type will act as an identifier for the measured value. It is inserted into any SMS messages and e-
mails sent from this Instrument Net input.
Additional information:
Measuring units
Number of decimals
This setting determines how many decimals you will see in an SMS message or e-mail sent from this
Instrument Net input.
Select the number of decimals you need, you can select from zero to eight digits after the decimal point.
The Chatter™ Data Logger stores the measured value internally with the maximum precision
regardless of this setting.
Call on alarm ON
Select between No and Yes.
If you select Yes, the Chatter™ Data Logger will make an
alarm call when the high limit is passed on a rising slope
and the Delay [Samples] is over
It will call all entries in the Alarm call list, starting with the
first entry.
Additional information:
Call lists
Setting the alarm call list
