Mounting in the field
Drill four holes, spacing as shown to the right.
Use screws and other mounting material suited for the
surface, on which the Chatter™ Data Logger will be
mounted.
Use some sort of strain relief for the sensor
cable, the cable gland must NOT be the only
support for the weight of the sensor and cable!
Place the lid on top of the housing, tighten all four screws.
