USERS MANUAL
CHATTER™ DATA LOGGER
192
Deviation detect
Name Reg
# Modbus
R/W Typ
e FW Description
Updated 190
0
R 3/16 U32 85000
8
Last time that signal values was updated (UTC Time
in seconds since 1970.1.1 and only signal that are
enable)
Now 190
2
R 3/16 F32 85000
8
Last calculation in input signal unit
AVG now 190
4
R 3/16 F32 85000
8
Average used for calculation of deviation detect
AVG next 190
6
R 3/16 F32 85000
8
Average for next period for calculation of deviation
detect
(0 when period function is not used)
Status register 190
8
R 3/16 U16 85000
8
Bit value 0 = off end 1 = active / on (Bit1 lsb - Bit16
msb)
Bit1 = 1 if fall rate alarm is active
Bit2 = 1 if rise rate alarm is active
Alarm register 190
9
R/W*
3/16
U16 85000
8
Bit value 0 = off end 1 = active / on (Bit1 lsb - Bit16
msb)
Bit1 = 1 if fall rate alarm is active
Bit2 = 1 if rise rate alarm is active
Fall rate alarm pulses total 191
0
R/W 3/16 U32 85000
8
Number of active pulses
Fall rate alarm pulses
today 191
2
R/W 3/16 U16 85000
8
Number of active pulses
Fall rate alarm pulses
yesterday 191
3
R/W 3/16 U16 85000
8
Number of active pulses
Rise rate alarm pulses total 191
4
R/W 3/16 U32 85000
8
Number of active pulses
Rise rate alarm pulses
today 191
6
R/W 3/16 U16 85000
8
Number of active pulses
Rise rate alarm pulses
yesterday 191
7
R/W 3/16 U16 85000
8
Number of active pulses
