USERS MANUAL
CHATTER™ DATA LOGGER
31
Re-assemble the Chatter Data logger
Make sure that the gasket is correctly placed in the green
plastic housing, then put the base plate back in place.
Ensure that none of the wires from the bas plate
are trapped between the gasket and the
baseplate.
Tighten all seven screws.
Tools
Type Size
Philips screw driver PZ 2
Do not use excessive force when tightening the
screws.
Turn the green plastic housing upside down, place the black
base on top of it. Make sure that the black base is inserted
correctly in the green plastic housing.
Hold the black base, twist the green plastic housing
clockwise
Make sure that the hole for the padlock in the black base is
aligned with the hole in the green plastic housing.
