Xylem CHATTER RTU and E-mail User Manual
Page 62
USERS MANUAL
CHATTER™ DATA LOGGER
62
The Depth below edge is only available if you select a rectangular weir.
A dditional inform ation:
Calculate Q points
Use this button to calculate the actual Q points corresponding to the selected weir type
Select number of Q points
Select which input you want to use to detect stormflows. Stormflows will not be recorded if you select
None.
sss
Q points
A Q point consist of two related values:
an input value, the actual head, measured in meters
a flow value for this head, measured in litres per second
