USERS MANUAL
CHATTER™ DATA LOGGER
190
Analog input
Name Reg
1 Reg
2 Reg
3 Reg
4 Modbus
R/W Typ
e FW Description
AI last updated 398 398 398 398 R 3/16 U32 Last time that signal values was
updated (UTC Time in seconds
since 1970.1.1 and only signal that
are enable)
AI1 - 4 Low limit status flag 400:
0
400:
1
400:
2
400:
3
R 3/16 B16
offs
et
Bit value 0 = off, 1 = active / on
AI1 - 4 High limit status
flag 401:
0
401:
1
401:
2
401:
3
R 3/16 B16
offs
et
Bit value 0 = off, 1 = active / on
AI1 - 4 Low limit alarm flag 402:
0
402:
1
402:
2
402:
3
R/W*
3/16
B16
offs
et
Bit value 0 = off, 1 = active / on
AI1 - 4 High limit alarm
flag 403:
0
403:
1
403:
2
403:
2
R/W*
3/16
B16
offs
et
Bit value 0 = off, 1 = active / on
AI1 - 4 scaled value 404 406 408 410 R 3/16 F32
AI1 - 4 Low limit pulses
total 412 432 452 472 R/W 3/16 U32 Number of active limit pulses
AI1 - 4 Low limit pulses
today 414 434 454 474 R/W 3/16 U16 Number of active limit pulses
AI1 - 4 Low limit pulses
yesterday 415 435 455 475 R/W 3/16 U16 Number of active limit pulses
AI1 - 4 High limit pulses
total 416 436 456 476 R/W 3/16 U32 Number of active limit pulses
AI1 - 4 High limit pulses
today 418 438 458 478 R/W 3/16 U16 Number of active limit pulses
AI1 - 4 High limit pulses
yesterday 419 439 459 479 R/W 3/16 U16 Number of active limit pulses
