Rectangular full width weir, side elevation
h is actual head, measured in meters
p is the depth from the crest to the bottom of the weir
measured in meters
Triangular V-notch weir, front elevation
α is the actual notch angle, measured in degrees
Triangular V-notch weir, side elevation
h is actual head, measured in meters
