Supported weir types
Rectangular full width weir, front elevation.
The notch width, b, equals the total weir width, B, both
measured in meters
Rectangular full width weir, side elevation
h is actual head, measured in meters
p is the depth from the crest to the bottom of the weir
measured in meters
Rectangular notch weir, front elevation
b is the notch width, measured in meters
B is the total weir width, measured in meters
