USERS MANUAL
CHATTER™ DATA LOGGER
198
Name Reg
# Modbus
R/W Type FW Description
Signal A signal type 199
6
R/W 3/16 U16 Signal type to show log for : 0 = None, 1 = AI,2
= INET, 3 = Flow
Signal A signal number 199
7
R/W 3/16 U16 Signal number selection: 0 = DI1,AI1,INET1,
Flow[L/s] .., 3 = DI4,AI4,INET4
Signal A log interval 199
8
R/W 3/16 U32 Interval between logs
Signal A log time 200
0
R/W 3/16 U32 Log time UTC for newest Log value (To sync.
SCADA with actual log time)
Signal A log value1 start
address 200
2
R/W 3/16 32 bit/16
bit
Newest log-value *
Signal A log value576 stop
address 32Bit 315
2
R/W 3/16 32 bit Oldest log value 32 bit (Depending on signal
log setup)
Signal A log value1152
stop address 16Bit 315
3
R/W 3/16 16 bit Oldest log value 16 bit (Depending on signal
log setup)
Signal B signal type 319
6
R/W 3/16 U16 Signal type to show log for : 0 = None, 1 = AI,2
= INET, 3 = Flow
Signal B signal number 319
7
R/W 3/16 U16 Signal number selection: 0 = DI1,AI1,INET1,
Flow[L/s] .., 3 = DI4,AI4,INET4
Signal B log interval 319
8
R/W 3/16 U32 Interval between logs
Signal B log time 320
0
R/W 3/16 U32 Log time UTC for newest Log value (To sync.
SCADA with actual log time)
Signal B log value1 start
address 320
2
R/W 3/16 32 bit/16
bit
Newest log-value *
Signal B log value576 stop
address 32Bit 435
2
R/W 3/16 32 bit Oldest log value 32 bit (Depending on signal
log setup)
Signal B log value1152
stop address 16Bit 435
3
R/W 3/16 16 bit Oldest log value 16 bit (Depending on signal
log setup)
Signal C signal type 439
6
R/W 3/16 U16 Signal type to show log for : 0 = None, 1 = AI,2
= INET, 3 = Flow
Signal C signal number 439
7
R/W 3/16 U16 Signal number selection: 0 = DI1,AI1,INET1,
Flow[L/s] .., 3 = DI4,AI4,INET4
Signal C log interval 439
8
R/W 3/16 U32 Interval between logs
Signal C log time 440
0
R/W 3/16 U32 Log time UTC for newest Log value (To sync.
SCADA with actual log time)
Signal C log value1 start
address 440
2
R/W 3/16 32 bit/16
bit
Newest log-value *
Signal C log value576 stop
address 32Bit 555
2
R/W 3/16 32 bit Oldest log value 32 bit (Depending on signal
log setup)
Signal C log value1152
stop address 16Bit 555
3
R/W 3/16 16 bit Oldest log value 16 bit (Depending on signal
log setup)
Signal D signal type 559
6
R/W 3/16 U16 Signal type to show log for : 0 = None, 1 = AI,2
= INET, 3 = Flow
Signal D signal number 559
7
R/W 3/16 U16 Signal number selection: 0 = DI1,AI1,INET1,
Flow[L/s] .., 3 = DI4,AI4,INET4
Signal D log interval 559
8
R/W 3/16 U32 Interval between logs
Signal D log time 560
0
R/W 3/16 U32 Log time UTC for newest Log value (To sync.
SCADA with actual log time)
Signal D log value1 start
address 560
2
R/W 3/16 32 bit/16
bit
Newest log-value *
Signal D log Value576
stop address 32Bit 675
2
R/W 3/16 32 bit Oldest log value 32 bit (Depending on signal
log setup)
Signal D log value1152
stop address 16Bit 675
3
R/W 3/16 16 bit Oldest log value 16 bit (Depending on signal
log setup)
