USERS MANUAL
CHATTER™ DATA LOGGER
191
INET input
Name Reg
1 Reg
2 Reg
3 Reg
4 Modbus
R/W Typ
e FW Description
INET Com error status flag. 796:
0
796:
1
796:
2
796:
3
R 3/16 B16
offs
et
Bit value 0 = off, 1 = active / on
INET Com error status flag. 797:
0
797:
1
797:
2
797:
3
R 3/16 B16
offs
et
Bit value 0 = off, 1 = active / on
INET Last updated 798 798 798 798 R 3/16 U32 Last time that signal values was
updated (UTC Time in seconds
since 1970.1.1 and only signal that
are enable)
INET1 - 4 Low limit status
flag 800:
0
800:
1
800:
2
800:
3
R 3/16 B16
offs
et
Bit value 0 = off, 1 = active / on
INET1 - 4 High limit status
flag 801:
0
801:
1
801:
2
801:
3
R 3/16 B16
offs
et
Bit value 0 = off, 1 = active / on
INET1 - 4 Low limit alarm
flag 802:
0
802:
1
802:
2
802:
3
R/W*
3/16
B16
offs
et
Bit value 0 = off, 1 = active / on
INET1 - 4 High limit alarm
flag 803:
0
803:
1
803:
2
803:
3
R/W*
3/16
B16
offs
et
Bit value 0 = off, 1 = active / on
INET1 - 4 scaled value 804 806 808 810 R 3/16 F32
INET1 - 4 Low limit pulses
total 820 840 860 880 R/W 3/16 U32 Number of active limit pulses
INET1 - 4 Low limit pulses
today 822 842 862 882 R/W 3/16 U16 Number of active limit pulses
INET1 - 4 Low limit pulses
yesterday 823 843 863 883 R/W 3/16 U16 Number of active limit pulses
INET1 - 4 High limit pulses
total 824 844 864 884 R/W 3/16 U32 Number of active limit pulses
INET1 - 4 High limit pulses
today 826 846 866 886 R/W 3/16 U16 Number of active limit pulses
INET1 - 4 High limit pulses
yesterday 827 847 867 887 R/W 3/16 U16 Number of active limit pulses
