Open the Chatter Data logger
Hold the black base, twist the green plastic housing counter
clockwise
Turn the green plastic housing upside down, remove the
screws at the circumference of the metal base plate. Retain all
screws for later.
Tools
Type
Size
Philips screw driver
PZ 2
Remove the base plate to gain access to the internal
components.
Take care not to damage the wiring from the
connector strips to the base plate!
