Batteries: The following battery management information is available under Status:
Installed Capacity
User entered system battery capacity in AH. Automatically entered
when using smart Lithium batteries.
On-Line Capacity
Available battery reserve from installed capacity value directly
connected to the bus. It is always the same value configured for
installed capacity except for when the smart lithium batteries are
utilized.
Current
Current flowing into or out of the batteries.
Number Of Strings
The total number of battery strings installed in the system.
Highest Temp
Highest battery temperature being measured by the thermal probes.
Temp Probes
Number of installed thermal probes.
Mid-Cell Volts
Number of installed Mid-cell voltage measurement modules.
Battery Test Result
Shows whether the most recent battery test was completed, and the
reserve time.
Next Test
The date of the next automatic battery discharge test. The automatic
discharge test feature must be enabled for this to work.
Live Reserve Time
Present value of battery reserve time calculated by the controller
Shunt Currents:
A maximum of six measured currents from each Distribution Control
and Monitoring module present in the system is displayed.
Disconnect States:
The status of the LVBD (Low Voltage Battery Disconnect) and
LVLD1-3 (Low Voltage Load) disconnects are displayed. “None” is displayed if
there are no contactors in the system.
Alarm Thresholds: Present alarm threshold settings in xx.xV format of the following system
alarms:
Float Voltage
Alarms
Very High Major, Very High Minor, BD Major and Very Low
Major
Boost Voltage
Alarms
Very High Major and High Minor
High Batt Temp
Highest temperature being measured by the thermal probes
Reserve Low
Low battery reserve time
High Ambient Temp High ambient temperature
Low Ambient Temp Low ambient temperature
Ringer Thresholds: Present status of up to two ringer chassis:
State
Ringer chassis present or not
VA
Output VA of ringer
Primary
Ringer module present in primary position
Secondary
Ringer module present in secondary/redundant position
